WARN® 9.5cti-s
The 9.5cti-s is the newest addition to the WARN Ultimate Performance winch lineup. A massive protective structure combined with sophisticated operator feedback delivers fast line speeds, and long duty cycles. The perfect winch for the serious off-roader.
- Now available with WARN Spydura™ synthetic rope with matte aluminum hawse fairlead
- New contactor control features exceptional durability, extra long life, and superior weather sealing
- Motor-mounted thermal sensor relays temperature information to winch operator by way of the hand-held remote control with LED indicator
- Redesigned remote control with thermometric indicator light
- Series-wound motor and 3-stage planetary geartrain deliver 9,500 lbs. of pulling capacity
- Extreme-duty winch sealing system
- High gloss, chip-resistant black powder coat finish over a massive cast-aluminum alloy housing
- Comes with synthetic winch rope, hook, remote control on 12' (3.7m) lead, and hawse fairlead
| 9.5cti-s SPECS |
| Winch model: 9.5cti-s (currently not CE compliant) |
| Part Number: 97600 |
| Rated line pull: 9,500 lbs., (4310 kgs.) single-line |
| Motor: Series wound |
| Electrical controls: Contactor |
| Remote Control: Remote switch, LED indicator, 12' (3.7m) lead |
| Geartrain: 3-Stage planetary |
| Gear ratio: 156:1 |
| Clutch (freespooling): Sliding ring gear |
| Brake: Automatic mechanical cone brake |
| Drum diameter/Length: 2.625"/9.0" (6.67cm/23cm) |
| Weight: 66 lbs. (30.0 kgs) |
| Rope: Synthetic -- 100', 3/8" diameter |
| Fairlead: Full radius matte aluminum hawse |
| Recommended Battery: 650 CCA minimum for winching |
| Battery leads: 2 gauge, 72" (1.83m) |
| Finish: High-gloss powder coat over primer undercoating |
| 12V DC PERFORMANCE SPECS | |||
| Line Pull Lbs.(Kgs.) | Line Speed FT./min(M/min.) | Motor Current | Pull by layer layer/Lbs(Kgs.) |
| 0 | 47.0 (14.32) | 42 amps | 1/9500 (4313) |
| 2000 (910) | 16.5 (5.02) | 140 amps | 2/8650 (3927) |
| 4000 (1810) | 12.0 (3.66) | 223 amps | 3/7920 (3595) |
| 6000 (2720) | 9.2 (2.80) | 307 amps | 4/7400 (3359) |
| 8000 (3630) | 7.1 (2.16) | 390 amps | 5/6940 (3150) |
| 9500 (4310) | 5.9 (1.80) | 452 amps | |
Above performance specs are based on first layer of drum
| Winch Dimensions: 23.1" L. x 6.3" D. x 10.4" H. (587mm L. x 160mm D. x 264mm H.) |
| Mounting Bolt Pattern: 10.0" x 4.5" (254mm x 114.3mm) |
